Luxury sailing catamaran for ocean navigation.
Length overall LAO: 14.95 m
Length at waterline Lwl: 14.95 m
Beam overall BOA: 8.34 m
Draught with keel T: 1.4 m
Displacement P: 20 T
Sail area S: 127 m²
Main sail: 70 m²
Genoa: 57 m²
Spinnaker: 220 m²
I = 19.84 m
P = 17.58 m
E = 5.64 m
J = 6.41 m
Mast height: 20 m
Engine: 2 x60 hp, hybrid engine in option
Fuel capacity: 2 x 372 L
Fresh water capacity: 2 x 340 L
Black water capacity: 2 x 335 L
Passenger capacity: 12
Design category A
Structure: composite – glass fibers and vinylester resin with carbon reinforcements, infusion
Produced by – WAVE CATAMARANS
