Sailing yacht for ocean navigation for travel around the world for a family of 5. Designed with an emphasis on low energy consumption and safety.
Length overall LAO: 13.00 m
Length at waterline Lwl: 12.20 m
Beam overall BOA: 4.00 m
Draught T: 1.9 m
Displacement P: 10.2 T
Ballast: 3.4 T
Sail area S: 95.40 m²
I = 16.90 m
P = 15.00 m
E = 5.40 m
J = 4.80 m
Engine: diesel 55hp
Fuel capacity: 400l
Fresh water capacity: 400l
Black water capacity: 88l
Wind generator, solar cells
Passenger capacity: 5-6
Design category A
Structure: composite – glass fibers and polyester resin on PVC foam
